Siemens 6ES7135-6HD00-0BA1 ET 200SP PLC analog output card AQ 4xU/I
-
6ES7135-6HD00-0BA1
-
Siemens
| Quantity: | |
|---|---|
6ES7135-6HD00-0BA1
The Siemens 6ES7135-6HD00-0BA1 is a high-performance analog output module (AQ 4xU/I Standard) designed for the decentralized SIMATIC ET 200SP system. Operating with 16-bit resolution, this standard-tier module provides 4 highly accurate channels to transmit voltage and current control signals to field actuators. It integrates seamlessly into standard ET 200SP BaseUnits, ensuring reliable and space-saving control cabinet setups.
Common model:
Series | Model |
Interface Modules (IM) | 6ES7155-6AU01-0BN0 |
Interface Modules (IM) | 6ES7155-6BA01-0CN0 |
Digital Input Modules (DI) | 6ES7131-6BF00-0BA0 |
Digital Input Modules (DI) | 6ES7131-6BH01-0BA0 |
Digital Output Modules (DQ) | 6ES7132-6BF00-0BA0 |
Digital Output Modules (DQ) | 6ES7132-6BH01-0BA0 |
Analog Input Modules (AI) | 6ES7134-6HD01-0BA1 |
Analog Input Modules (AI) | 6ES7134-6GD01-0BA1 |
Analog Output Modules (AQ) | 6ES7135-6HD00-0BA1 |
Analog Output Modules (AQ) | 6ES7135-6FB00-0BA1 |
BaseUnits (BU) | 6ES7193-6BP00-0DA0 |
BaseUnits (BU) | 6ES7193-6BP00-0BA0 |
Server Modules | 6ES7193-6PA00-0AA0 |
Key Features & Technical Specifications
Channel Density: Features 4 analog output channels in a compact, slice-type physical design.
High Precision: Delivers exceptional signal transmission with 16-bit resolution (including sign) for smooth actuator regulation.
System Diagnostics: Provides comprehensive diagnostics including short-circuit detection for voltage outputs and wire-break detection for current loops.
Substitute Value Support: Configurable to output safe substitute values or hold last values in the event of a CPU stop.
BaseUnit Compatibility: Mounts easily on standard Type A0 or A1 BaseUnits with color-coded CC00 terminals.
Compact Integration: Extremely slim 15 mm module width allows panel builders to optimize space inside high-density control cabinets.
Applications
The 6ES7135-6HD00-0BA1 analog output module is widely applied in modern distributed automation systems where precise speed, position, or flow control is required. Thanks to its versatile voltage and current output capabilities, it is perfectly suited for regulating proportional hydraulic valves, driving frequency inverters, commanding servo actuators, and controlling temperature regulators in process industries. Whether deployed in automotive assembly halls, food and beverage processing lines, or smart water management facilities, this ET 200SP AQ card guarantees stable analog signal routing.
Advantage
1.We are a certified system integrator holding an official Siemens PI license/certificate.
2.Short delivery times, guaranteed product quality, and a 2-year warranty.
3.We at GKone own our own factory, which allows us to stock standard Siemens models and manufacture industrial control cabinets.
4.Factory staff are trained in packaging, ensuring secure packing.
