Siemens 6ES7422-1BL00-0AA0 S7-400 SM 422 DO 32x24VDC 0.5A Module
-
6ES7422-1BL00-0AA0
-
Siemens
| Quantity: | |
|---|---|
6ES7422-1BL00-0AA0
The 6ES7422-1BL00-0AA0 SM 422 output module is widely deployed across large-scale process automation and discrete manufacturing plants. It functions as the primary digital switching card for controlling pneumatic valves, motor starters, warning lamps, solenoids, and interlock relays in automotive assembly lines, chemical refining plants, power generation stations, and bulk material handling systems. By offering high-density 32-point 24V DC switching in a standard S7-400 footprint, this SIMATIC module minimizes hardware rack count and wiring complexity.
Key Features & Technical Specifications
32 High-Density Channels: Features 32 digital outputs in a single S7-400 rack slot to optimize control cabinet spatial footprint.
24V DC / 0.5A per Channel: Delivers a rated output switching current of 0.5 A at 24V DC, with up to 4A aggregate per group.
Optical Isolation: Provides high-voltage optocoupler insulation between internal backplane bus and field load wiring circuits.
Group Switching Support: Channels are divided into isolated groups to allow flexible field supply voltage distribution.
Front LED Diagnostics: Includes dedicated status LEDs per output channel for instant visual troubleshooting and signals verification.
40-Pin Front Connector: Connects seamlessly via standard S7-400 40-pin front connectors with screw or spring terminals.
Rugged Heavy-Duty Build: Built with industrial shielding to withstand high electrical noise, thermal stress, and mechanical vibration.
